3.4.1 Standard interface / Parallel interface
The analog mode can be set up to operate in two different modes, standard or parallel. Default
mode is standard.
Table below shows input/output connections of the two modes and straps settings for selecting
standard or parallel mode. Notice that you need to cut some straps and likewise to solder some
straps for changing to parallel mode. The straps are located near the D-SUB25 on bottom side
of the PCB.
D-Sub 25
X108
(backplane)
Standard Mode
Straps
(standard)
Parallel Mode
Straps
(parallel)
1
Spare
-
Sum Interlock *
ST801=close
2
ISO RTN
-
ISO RTN
-
3
Spare
-
ON/OFF status,
low=ON *
ST803=close
4
Spare
-
/Ready status
Low=Ready *
ST804=close
5
ON
ST817=close
ST805=open
Sum Ext interlock
*
ST817=open
ST805=close
6
COM
(GNDD)
ST818=close
ST806=open
Earth leak status
ST818=open
ST806=close
7
I-MON
ST819=close
ST807=open
Overcurrent status
ST819=open
ST807=close
8
RTN AUX
(GNDA)
ST821=close
ST809=open
GND
(Parallel)
ST821=open
ST809=close
9
V-set Readback
ST823=close
ST811=open
/OFF control
ST823=open
ST811=close
10
I-set Readback
ST825=close
ST813=open
RESET control
ST825=open
ST813=close
11
I-set Parallel
-
I-set Parallel
-
12
V-set serial
-
V-set serial
-
13
GNDA
-
GNDA
-
14
ISO TTL/CMOS
-
ISO TTL/CMOS
-
15
VP 10V
ST815=close
ST802=open
LOC/REM status
Low=LOC *
ST815=open
ST802=close
16
IP 10V
-
SOLL-WERT &
SOLL-WERT
sense
-
17
Fault relay
-
Fault relay
-
18
Fault relay
-
Fault relay
-
19
V-MON
-
V-MON
-
20
VP RTN
ST820=close
ST808=open
Phase fail status *
ST820=open
ST808=close
21
+15V AUX
ST822=close
ST819=open
GND
(parallel)
ST822=open
ST819=close
22
-15V AUX
ST824=close
ST812=open
ON control
ST824=close
ST812=open
23
IP RTN
-
SOLL-WERT
GND & SOLL-
WERT sense GND
-
24
V-MON RTN
-
V-MON RTN
-
25
I-MON RTN
-
I-MON RTN
-
* Open Collector output
