MAGNET POWER SUPPLY SYSTEM 9100
6
DANFYSIK A/S - DENMARK.
1.2 Specifications
AC INPUT
Mains, voltage: 400 VAC, 3 phase, 47 - 63 Hz.
Control voltage: 230 VAC, 47-63 Hz.
AC voltage variation: ±10%
See page 58 for connection to AC mains connector.
DC OUTPUT
Power Range up to 12 kW
Current: 50 A - 100 A - 150 A - 200 A versions
Voltage: 60 V
Regulation Topology: Constant current regulation
Converter Type: Primary switching type that operate after the Zero
voltage switch-mode principle
PERFORMANCE
Warm up time (cold): 30 min.
Warm up time (stand-by): 15 min
Drift (long term 8 hours): ±10ppm
Line regulation
± 10% slow, T > 1 min.: ±5ppm
± 1% fast, T > 3 m sec.: ±5ppm
Load regulation
± 10% resistance change: ±5ppm
Output ripple and noise
Voltage – peak to peak: < 100 mV @ 0-100 kHz
Load Range
Time Constant (L/R): 0 - 1 sec
Inductance (L): 0 - 1 H (standard)
Temperature coefficient
Ambient 15 – 40° C: 5ppm/°C
Ambient 15 – 30° C: 1ppm/°C
Current setting resolution: 20 bit DAC
Current reproducibility: ± 10ppm
Absolute current calibration: -0 / +400ppm
