3.2.5 Control Menus
The table below lists the standard menus. (Horizontal pop up layout)
Scroll
menu
Sub menu 1
Sub menu 2
Sub menu 3
Comment
SET
Setting of output current
CURRENT
Set output current immediately
CURRENT d
elayed
Set output current after
MEM
Memory function
RCL
Reg 0 9
Recalls one memory
STO
Reg 0 9
Stores to a memory
MAX/MIN
Set current to one end.
0%
Set current to zero
100%
Set current to max
CMD
Control Command line
REM
Set to Remote Control
LOC
Set to Local control
ADR
Select a multidrop address
INTL
Display Interlocks / Status
INT
Internal Interlocks
CROWBAR OFF
DC OVERCURRENT (OCP)
DC OVERVOLTAGE (OVP)
15VP OK
PHASE FAILURE
EARTH LEAKAGE FAILURE
FAN
MPS OVERTEMPERATURE

See also the list below the tables.
EXT
External interlocks
EXTERNAL INTERLOCK 0
EXTERNAL INTERLOCK 1
EXTERNAL INTERLOCK 2
EXTERNAL INTERLOCK 3
POL
Change output polarity
POS +
Set polarity to +
NEG -
Set polarity to -
+<>-
Invert output polarity
