STXC2 User’s guide
Version 2.0
22 of 30
When the sub menu Control outputs is selected:
Here the actual values for output signals 0-100% is indicated.
When the sub menu On/off inputs is selected:
Here the actual status for failure inputs and de-icing the heat exchanger (De-ice bypass) are
indicated. If the ventilation unit is working correctly the status will show Ok. If a data point is in
alarm, status will show Alarm (See chapter 2.7.1 Critical failure reset).
The heat exchanger de-icing status is shown as Off (no icing up) or On (icing up).
Reheat % 100
Preheat % None
Heat recovery % 100
Damper % 000
Supply fan % 000
Exhaust fan % 000
Extra cooling % 000
Analog output 1 % 000
Analog output 2 % 000
Main menu Monday 12:21
Technical data
Control outputs
Main menu Monday 12:21
Fail preheat Alarm
Fail reheat Ok
Fire supply Ok
Fire exhaust Ok
Fan fail supply Ok
Fan fail exhaust Ok
Flow supply Ok
Flow exhaust Ok
Filter supply Ok
Filter exhaust Ok
Heat wheel Ok
Technical data
On/off inputs
De-ice bypass Off
To Next Page
