Darex XT-3000 - Parts List - Machine Rev B Serial Number; Optional Accessories

30
Machine Parts List-Beginning Serial # 5015 Rev B
XT-3000 Exploded View Rev B-page 37
Exploded View / Alignment Rev B-page 39
Not Shown PP09090PF - MACHINE COVER 41) - PP02022TF - PUSHER SHAFT CAP***
Not Shown SA12072EA - 230V VACUUM ASSEMBLY COMPLETE 40) - PP16220XF - PUSHER WEDGE***
Not Shown SA12075EA - 115V VACUUM ASSEMBLY COMPLETE 39) - PP02028RF - WEDGE RETURN SPRING***
Not Shown SA16400TA- 3MM - 12MM STANDARD CHUCK COMPLETE 38) - PP16230TF - PUSHER GUIDE TUBE***
Not Shown SA16450TA- 12MM - 21MM STANDARD CHUCK COMPLETE 37) - PP16227BF - PUSHER GUIDE TUBE SUPPORT***
N
ot Shown PP16480SF - CHUCK WRENCH )63 - PP16235TF - PUSHER SHAFT***
Not Shown SA16936TA - PROTECTIVE EYE SHIELDS (220V MACHINES ONLY) 35) - PP16237RF - PUSHER BAR RETURN SPRING***
Not Shown SA16937TA - POINT SPLIT PLUG/LEASH ASSEMBLY (220V MACHINES ONLY) 34) - PP16240BF - MATERIAL ADJUST BRACKET***
95) - PP16934PF - 3/8 DOME PLUG (115V MACHINES ONLY) 33) - PP02030TF - PUSHER RETURN REAR SPRING GUIDE***
95) - SA16936TA - EYESHIELD ASSEMBLY (220V MAC
HINES ONLY) 32) - PP16338FF - 3/32 X 3/8 DOWEL PIN***
93) - PP16632SF - DOCKING LEVER 31) - SA16227BA - PUSHER SHAFT ASSEMBLY COMPLETE***
92) - PP16634TF - DOCKING LEVER BOLT 30) - SA16215XA - PAWL ARM ASSEMBLY COMPLETE**
91) - PP03923FF - LOCATING PIN 1/4x1/2
29) - PP16283RF - MATERIAL LENGTH ADJUST SPRING*
90) - SA16075TA - 115v MOTOR/HUB ASSEMBLY )82 - PP16285TF - MATERIAL LENGTH ADJUST SCREW*
90) - SA16077TA - 220v MOTOR/HUB ASSEMBLY 27) - PP16385FF - 5MM X .8X 45MM SHCS (4 REQUIRED)*
89) - PP02674PF - DOME PLUG (115V MACHINES ONLY) 26) - PP16212BF - PUSHER BAR*
89) - PP12040EF - 220v EMERGENCY STOP (220V MACHINES ONLY) 25) - SA08560LA - BEARING W/ 1/4 - 20 BHCS (SET OF 3)*
88) - SA16003CA - 220V BASE CASTING ASSEMBLY (REV B) 23) - PP16205SF - BRAKE BRACKET*
87) - PP16035EF - 115v SWITCH BREAKER 22) - SA16615SA
- PIVOT LOCK LEVER ASSEMBLY*
87) - PP16037EF - 220v SWITCH BREAKER 21) - PP16245TF - ALIGNMENT TUBE*
86) - PP12065EF - ELECTRICAL RECEPTACLE 21) - PP16242TF - OSG ALIGNMENT TUBE*
85) - PP16009SF - RECEPTACLE PLATE 20) - PP16275TF - ALIGNMENT TUBE LOCK BOLT*
84) - PP16042EF - ELECTRICAL BOTTOM COVER 19) - PP16250TF - ALIGNMENT TUBE NUT*
83) - -SA16030TA - VACUUM TUBE/NUT ASSEMBLY 17) - SA16271XA - SLIDE HANDLE ASSEMB
LY*
82) - SA16020SA - GRIT TRAY ASSEMBLY* 16) - PP16202TF - ALIGNMENT STORAGE LINER*
81) )HCAE 4( SCHB MM61 X MM6 & TEEF REBBUR - AP46680AS -
80) REVOC DRAUG LEEHW - FS34061PP -
79) - SA16070TA - GRIND WHEEL RETAINER W/ LOCK WASHER & SHCS (3 EACH)
Optional Accessories
78) - PP16060GF - CBN POINT SPLIT GRINDING WHEEL 100 GRIT nwohS toN SA16500TA - LARGE DRILL CHUCK 21MM - 30MM*
78) - PP16062GF - DIAMOND POINT SPLIT GRINDING WHEEL 260 GRIT (OPTIONAL) Not Shown SA16565XA - LARGE DRILL ALIGNMENT FIXTURE - 30MM*
77) - PP16050GF- CBN GRINDING WHEEL 180 GRIT Not Shown SA16580XA - LARGE DRILL SHARPENING FIXTURE - 30MM*
77) - PP16052GF - DIAMOND GRINDING WHEEL 180 GRIT (OPTIONAL) Not Shown LEX 100
- XY TABLE ATTACHMENT COMPLETE
76) - SA16945BA - POINT SPLIT DEPTH ASSEMBLY* Not Shown LEX150 - COUNTERSINK ATTACHMENT COMPLETE
75) - PP16935TF - POINT SPLIT CHUCK TUBE* Not Shown LEX 150INTL- COUNTERSINK ATTACHMENT (w/ metric collets)
73) - PP16925TF - POINT SPLIT TUBE* Not Shown PP16862TF - PP16862TF - 3 FLUTE COUNTERSINK CAM (OPTIONAL)
73) - PP16922TF - OSG POINT SPLIT TUBE Not Shown PP16864TF - P
P16864TF - 6 FLUTE COUNTERSINK CAM (OPTIONAL)
72) - PP16930TF - POINT SPLIT FAN ADJUSTER* Not Shown LEX 200 - BRAD POINT ATTACHMENT COMPLETE
72) - PP16932TF - OSG POINT SPLIT FAN ADJUSTER Not Shown SA16916TA - BRAD POINT CHUCK 3MM - 12MM*
71) - PP16940TF - POINT SPLIT NUT* Not Shown SA16918TA - BRAD POINT CHUCK 12MM - 21MM (OPTIONAL)
70) - SA16925TA - POINT SPLIT ASSEMBLY COMPLETE* (#76 - #71) Not Shown SA16950BA - LEX 250 -
STEP DRILL ATTACHMENT COMPLETE*
Exploded View / Sharpening Fixture All Models-page38
Not Shown SA16975TA - STEP DRILL CHUCK 3MM - 12MM*
Not Shown SA16980TA - STEP DRILL CHUCK 12MM - 21MM (OPTIONAL)
60) - SA16615SA - PIVOT LEVER ASSEMBLY* Not Shown SA16970XA - STEP DRILL ALIGNMENT FIXTURE*
61) - PP16610TF - SHARPNEING TUBE PIVOT SHAFT* Not Shown SA16950BA - STEP DRILL SHARPENING FIXTURE*
59) - PP16640TF - PIVOT LOCK NUT* Not Shown LEX 300 - 90° -120° POINT ATTACHMENT COMPLETE*
58) -
PP16630BF - DOCKING PLATE Not Shown SA16995XA - 90° - 120° SHARPENING FIXTURE
57) - PP16650RF - RETURN SPRING* Not Shown SA16890TA - 90° POINT CHUCK 3MM - 12MM*
56) - SA16645TA - SPRING TENSIONER ASSEMBLY* Not Shown SA16880TA - 90° POINT CHUCK 12MM - 21MM (OPTIONAL)
55) - SA16652TA - FEED BEARING ASSEMBLY* Not Shown SA16484TA - LEFT HAND CHUCK 3MM - 12MM* (OPTIONAL)
54) - SA16657TA - SWING BEARING ASSEMBLY* Not Shown SA16
488TA - LEFT HAND CHUCK 12MM - 21MM (OPTIONAL)
Not Shown LEX350 - MINIATURE DRILL CHUCK ATTACHMENT (OPTIONAL)
Not Shown LEX400 - AUTO SHARPENING ATTACHMENT 3 - 12MM (OPTIONAL)
Not Shown LEX450 - AUTO SHARPENING ATTACHMENT 12-21MM (OPTIONAL)
Not Shown LEX500 - AUTO SHARPENING ATTACHMENT 3 - 21MM (OPTIONAL)
53) - PP16100CF - PIVOT BASE CASTING*
52) - PP16600XF - SHARPENING TUBE*
51) - PP16605TF - SHARPENING TUBE LINER*
50) - SA16600XA - 118° - 150° SHARPENING FIXTURE COMPLETE* (#60 -
#51)
88) - SA16001CA - 115v BASE CASTING ASSEMBLY (REV B) 24) - PP16280TF - BRAKE STOP SET SCREW*
