SA17060TA Auto Controller/Display
115V Complete
1) - SA17230EA Interface Harness Assembly
2) - SA17173TA Mounting Bracket Assembly
3) - SA17185EA Display Assembly
4) - PP117228PF Housing Main Side
5) - PP17231EA Interface PWB
6) - PP17180FF Dual Lock Mounting Tape
7) - PP17225PF Housing Base Side
8) - PP17190EF Display PMB w/LCD
9) - PP17195PF Display Housing
10) - PP17198EF Membrane Switch Panel
11) - PP17238EF 115V Relay
11) - PP17240EF 230V Relay
Not Shown -
PP17250FF
Vacuum Fuse 115V
Not shown -
PP12057EF
Vacuum Fuse 230V
SA17061TA Auto Controller/Display
230V Complete
Controller/Display Parts List
