Darex XT-3000 - Auto Specification Sheet

62
Auto Sharpening Attachment Specification Sheet
XT-3000 Auto Sharpening Attachment
Specifications
Warranty - 1 year on defective parts
A) Geared Chuck:
Chuck Body Material - 303 Stainless
Knob and Cam Material - 12L14
Capacity - 3mm - 12mm or 12mm - 21mm
Gear Spline - 45 Tooth
Weight - 2.1lbs each (0.95kg)
B) Sharpening Fixture:
Gear Material - Acetal;
Gear Motor - 12 VDC, rated current 350 mA, typical current 150 mA
Home switch - Slotted Optical
Weight - 6.0 lbs ( 2.72 kg)
C) Controller/Display:
Housing Material - Glass filled, Acrylonitrile Butadiene Styreme (ABS)
STN Graphic LCD w/ Green LED back light
Weight - 1.5lbs (0.68 kg)
Power Inlet:
Power Outlet:
Voltage: 115v~ Voltage: 115v~
Frequency: 60hz Current : 8A Max
Current: Fusing : 8A Time Lag
Grind Motor: 3.2A
Accessory: 8.0A
A
C
B
