XT-3000 PARTS LIST
Exploded View / Alignment Assembly Rev A-page 36
41) - PP02022TF - PUSHER SHAFT CAP***
Exploded View / Machine Rev A-page 41
40) - PP16220XF - PUSHER WEDGE***
93) - PP16632SF - DOCKING LEVER 39) - PP02028RF - WEDGE RETURN SPRING***
92) - PP16634TF - DOCKING LEVER BOLT 38) - PP16230TF - PUSHER GUIDE TUBE***
91) - PP16005TF - LOCATING PIN 37) - PP16225BF - PUSHER GUIDE TUBE SUPPORT***
90) - SA16077TA - 230v MOTOR/HUB ASSEMBLY 36) - PP16235TF - PUSHER SHAFT***
89) - PP12040EF - 230v EMERGENCY STOP (INTERNATIONAL
MACHINES ONLY)
35) - PP16237RF - PUSHER BAR RETURN SPRING***
88) - PP12065EF - ELECTRICAL RECEPTACLE 34) - PP16240BF - MATERIAL ADJUST BRACKET***
87) - PP16035EF - 115v SWITCH BREAKER 33) - PP02030TF - PUSHER RETURN REAR SPRING GUIDE***
87) - PP16037EF - 230v SWITCH BREAKER 32) - PP16338FF - 3/32 X 3/8 DOWEL PIN***
86) - SA08664PA - RUBBER FEET & 6MM X 16MM BHCS (4 EACH) 31) - SA16225BA - PUSHER SHAFT ASSEMBLY COMPLETE*** (#41 - #32)
85) - SA16040EA - ELECTRICAL BOTTOM COVER W/ (4) 6-32 TYPE F
86) - SA08664PA - RUBBER FEET & 6MM X 16MM BHCS (4 EACH) 30) - SA16215XA - PAWL ARM ASSEMBLY COMPLETE**
85) - SA16040EA - ELECTRICAL BOTTOM COVER W/ (4) 6-32 TYPE F 30) - PP02079TF - PAWL ARM BOLTS (2 REQUIRED)**
30) - PP02082RF- PAWL ARM RETURN SPRING**
84) - PP12076TF- VACUUM TUBE ATTACHMENT NUT* 30) - PP04219FF - 6-32 X 1/4 BHCS (2 REQUIRED)**
83) - PP16030TF - VACUUM TUBE* 30) - PP02078NF - CARBIDE PAWLS ( 2 REQUIRED)**
-SA16030TA - VACUUM TUBE/NUT ASSEMBLY 30) - PP16215XF - PAWL ARMS (2 REQUIRED)**
82) - SA16020SA - GRIT TRAY ASSEMBLY* 29) - PP16283RF - MATERIAL LENGTH ADJUST SPRING*
81) - PP12240FF - WHEEL GRD CSTING 4 MM X 18MM SHCS (3
REQUIRED)
28) - PP16285TF - MATERIAL LENGTH ADJUST SCREW*
80) - PP16045CF - WHEEL GUARD CASTING 27) - PP16334FF - 5MM X 22MM SHCS (4 REQUIRED)*
79) - SA16070TA - GRIND WHEEL RETAINER W/ 3 BOLTS 26) - PP16210BF - PUSHER BAR*
25) - SA08560LA - BEARING W/ 1/4 - 20 BHCS (SET OF 3)*
78) - PP16062GF - DIAMOND POINT SPLIT GRINDING WHEEL 260
GRIT
24) - PP16280TF - BRAKE STOP SET SCREW*
78) - PP16060GF - CBN POINT SPLIT GRINDING WHEEL 100 GRIT 23) - PP16205SF - BRAKE BRACKET*
77) - PP16052GF - DIAMOND GRINDING WHEEL 180 GRIT 22) - SA16615SA - PIVOT LOCK LEVER ASSEMBLY*
77) - PP16050GF- CBN GRINDING WHEEL 180 GRIT 21) - PP16245TF - ALIGNMENT TUBE*
Not Shown PP16480SF - CHUCK WRENCH 20) - PP16275TF - ALIGNMENT TUBE LOCK BOLT*
76) - SA16945BA - POINT SPLIT ADJUSTING LEVER* 19) - PP16250TF - ALIGNMENT TUBE NUT*
75) - PP16935TF - POINT SPLIT CHUCK TUBE* 18) - PP16200CF - ALIGNMENT CASTING*
74) - PP16340FF - 5 MM X 50 MM SHCS (4 REQUIRED)* 17) - SA16270XA - SLIDE HANDLE ASSEMBLY*
73) - PP16925TF - POINT SPLIT TUBE* 16) - PP16202TF - ALIGNMENT STORAGE LINER*
72) - PP16930TF - POINT SPLIT FAN ADJUSTER* 15) - SA16200CA - ALIGNMENT ASSEMBLY COMPLETE* (#31 - #16) & (#41 - #32)
71) - PP16940TF - POINT SPLIT NUT*
70) - SA16925TA - POINT SPLIT ASSEMBLY COMPLETE* (#76 - #71)
75) - PP16935TF - POINT SPLIT CHUCK TUBE*
74) - PP16340FF - 5 MM X 50 MM SHCS (4 REQUIRED)*
73) - PP16925TF - POINT SPLIT TUBE*
72) - PP16930TF - POINT SPLIT FAN ADJUSTER*
71) - PP16940TF - POINT SPLIT NUT*
70) - SA16925TA - POINT SPLIT ASSEMBLY COMPLETE* (#76 - #71)
Machine Parts List-Serial # 0 - 5014 Rev A
