■Remote setting:
MODE
0: BACK UP
1: RESIDENTIAL
2: BACK UP WITHOUT FEED IN
3: RESIDENTIAL WITHOUT FEED IN
4: TOU WITHOUT BATTERY FEED IN
5: TOU WITH BATTERY FEED IN
OPERATING MODE
STARHOUR
0~23
HIGH PRICE PERIOD START HOUR
STARMIN
0~59
HIGH PRICE PERIOD START MINUTE
ENDHOUR
0~23
HIGH PRICE PERIOD END HOUR
ENDMIN
0~59
HIGH PRICE PERIOD END MINUTE
MULTI-MODULE
SETTING
0: SINGLE
1: PARALLEL
2: THREE PHASE
MALFUNCTION!
BATTERY TYPE
0: NO SETTING
1: LEAD-ACID
2: GLODEN CROWN
3: DARFON GROWATT
BATTERY CURRENT
10A ~ 60A
MAX BATTERY CHARGING CURRENT
BATTERY SHUTDOWN VOLTAGE
44.0V ~ 48.0V
BATTERY CUT OFF VOLTAGE
BATTERY FLOATING VOLTAGE
54.0V ~ 58.0V
BATTERY FLOATING CHARGING VOLTAGE
BATTERY RESERVE PERCENT
10% ~ 60%
BATTERY RESERVE QUANTITY IF GRID CONNECTED
RAMP_RATE_PERCENTAGE
0~50%
0: DISABLE, 1~50%
VOLT/VAR Q(V)
0~3
DEGREE LEAD/LAG
ABB
A 0: DISABLE, 1: LEAD, 2: LAG,
BB: 2 DIGIT VALUE
