GRID SUPPORT PARAMERTERS
Model(s)
H5000
Certificate #
UL1741SA
Manufacturer Stated Tolerance
Value
unit
Voltage
2%
%
Current
5%
%
Frequency
2%
%
Time
0.1 sec
Sec
INVERTER (INPUT) SIDE VOLTAGE
VALUE
RATING
UNITS
DESCRIPTION
V input
max rating
500
Volts
Max input voltage
V
operating RANGE
250~430
Volts
Maximum power point track range
I
DC rating
13A/13A
Amps
DC input current rating for each string
INVERTER AC (OUTPUT) SIDE
VALUE
RATING
UNITS
DESCRIPTION
V
AC-NOMINAL(Phase-neutral)
120
Volts
Nominal Voltage Phase-neutral (if neutral available)
V
AC-NOMINAL(Phase-phase)
240
Volts
Nominal Voltage Phase-phase
P
OUT
5
KW
Active Power Output
I
NOMINAL-OUTPUT
21
Amps
Nominal current per phase
I
MAXIMUM-OUTPUT (at Vlow)
24
Amps
Maximum output current at lowest operating voltage
VOLTAGE RIDE-THROUGH
Trip time
DESCRIPTION
OV
t
TRIP (V>120%)
0.166 sec
Trip time when the voltage is above 288Vac
@I
RMS,max
t
TRIP (110%<V<120%)
13 sec
Trip time when the voltage range is between 264Vac and 288Vac
Normal
I
RMS@(V=90%~109%
-
No applicable when the voltage range is between 211.2Vac and 264Vac
UV
t
TRIP (70%<V<88%)
21 sec
Trip time when the voltage range is between 168Vac and 211.2Vac
@I
RMS,max
t
TRIP (50%<V<70%)
11 sec
Trip time when the voltage range is between 120Vac and 168Vac
t
TRIP (V<50%)
1.5 sec
Trip time when the voltage is below 120Vac
