SPECIFICATIONS
SOLAR DC INPUT
Maximum Power
6500W
Operation / MPPT Voltage Range
120 to 500VDC / 250 to 430VDC
Minimum Start Voltage
150VDC
Maximum Input Current
13A / 13A (two string input)
AC OUTPUT TO LOAD
Output Power (Continuous) @ 25°C
5000W
Output Power (Continuous) @ 40°C
4500W
Overload 40/5/1sec @ 25°C
5500/6500/7500W
Rated Output Current
21 A ( @120V and 240 V)
Output Frequency (Selectable)
50/60Hz
Output Voltage
L-N: 120V ± 3%; L-L: 240V ± 3%
Total harmonic distortion (THD) at rated power
< 5%
AC INPUT FROM GRID (GRID SUPPORT)
AC Input Voltage Limits (Bypass)
L-L: 180 to 280V (240 V nominal)
Automatic Transfer Relay Rating / Typical Transfer Time
33A / 20ms
AC Input Frequency Range (Bypass)
55 to 65 Hz
AC OUTPUT TO GRID
Grid Sell Current Range ( Depending On Operation Mode)
0 to 24A (240V)
Grid Sell Voltage Range
L-L: 211 to 264V ± 3.0V
Grid Sell Frequency Range
59.4 to 60.4Hz ± 0.05Hz
EFFICIENCY
Peak PV to Grid
96%
CEC weighted PV to Grid
95.5%
DC BATTERY CHARGER
Maximum Charge Current
60A
Output Voltage Range
42 - 60V (48V Nominal)
Power Factor Corrected Charging
>98%
Compatible Battery Types
AGM (default), Gel, Li-ion, custom
Battery Bank Range
200 - 600Ah (Suggested)
GENERAL SPECIFICATIONS
Product weight
35.0 kg (71.2lb)
Product dimensions (H x W x D)
69 x 44.5 x 15cm (27.2 x 17.5 x 5.9in)
IP degree of protection
NEMA Type 1 Indoor
Temperature
Operating: 0 to 55°C (power derated above 40°C )
Storage: -25 to 70°C
Compliances
UL1741SA, FCC Class B, IEEE 1547
FEATURES
System monitoring and network communications
Available
Intelligent features
Six operation modes for Grid sell, peak load shave, PV energy generated
and prioritized consumption of PV, Grid or battery
Auxiliary port
0 to 12 V, maximum 250 mA DC output, selectable triggers
