A-10 SD460 Laminating System

5. Loadthenewrolloflaminator

overlaymaterial.

A. Putthebluesupplyspoolon

thebluesupplyspindle ofthe

cartridge(c).Theoverlay

supplyrollcangoononlyone

wayandonlyfitsonthecorrect

spindle.

B. Puttheemptysilvertake‐up

spoolonthesilvertake‐up

spindle(d).

C. Turnthetake‐upspool

clockwisetoremoveslackfrom

thematerial(e).Theoverlay

materialloadsinanS‐shape.

Makesurethattheoverlay

materialisbetweentheguideson

boththetake‐upandsupplysides

ofthecartridge.

6. Closethelaminatorcartridgegate(f).

Pushitinuntilthelatchclicksin

place (g).Makesurethattheoverlay

materialisnotpinchedbythe

cartridgegate.

7. Replacetheloadedlaminator

cartridgeintheprinter.

8. RemovetheL2(orange)cartridgefromthelaminator,ifinstalled.

9. Repeatsteps3through7toloadtheoverlayontothecartridge.

10. Closethelaminatordoor.
