6 Installation

Load the Print Ribbon

Loadtheribbonwhenyouinstalltheprinterandwhentheribbonrunsout.

1. Opentheprintercover.

2. Removetheprintribboncartridge.

3. Loadafullrollofprintribbon(theblue

spool)ontothespindleclosesttothe

cartridgehandle.

4. Placethesilvertake‐upspoolonthe

spindlewiththeblackgear.

5. Windthetake‐upspool

counterclockwiseonefullturn.

Load the Cleaning Sleeve

Loadanewcleaningsleevewitheachnewroll

ofprintribbon,ifyounoticedebrisonthe

printedcards,orifthecleaningsleeveisno

longersticky.

Theprintershipswiththecleaningroller

spindleinstalledontheprintribbon

cartridge.

1. Removethecleaningrollerspindlefrom

theribboncartridgeandslidethespindle

intothecontinuouscleaningsleeve(a).

2. Placethespindlewithcleaningsleeve

ontotheribboncartridge(b).

3. Removetheprotectivewrapperfromthecleaningsleeve(c).
