32 • Instrument Specifications Datacolor 110 User's Guide
Instrument Specifications
Specifications are subject to change without notice.
ITEM DESCRIPTION
Instrument Type
Dual beam integrating sphere with xenon flash lamp.
Measuring Geometry
Diffuse illumination, 8º viewing in conformance with CIE
publication No. 15.2 Colorimetry.
Illumination Source
Pulsed xenon, filtered to approximate D65.
Spectral Analyzer
Proprietary SP 2000 analyzer with dual 256-diode array and
high-resolution holographic grating.
Wavelength Range
400 – 700nm
Effective Bandwidth
10nm
Wavelength Resolution
2nm
Photometric Range
0 to 200%
Photometric Resolution
0.003%
Aperture Configuration
Large Area View. 22 mm
Small Area View. 9mm
Ultra-Small Area View. 6.5mm
Power
100 to 240 VAC, 47 to 63 Hz, 60 VA
Performance—
Repeatability*
0.05 CIELAB Max on white ceramic
Performance—
Reproducibility*
0.2 CIELAB ΔE average of 12 BCRA tiles
Absolute Operating
Environment
5º to 40º C, 20-85% RH, non-condensing
Interface
RS232 9600/19200 baud ~or~ USB v1.1 or higher
Warranty
1-year parts and labor. Extended warranty available.
Dimensions without Drawer English Metric
Height 6.5 inches 16.51 cm
Width 6.75 inches 17.15 cm
Depth 12.375 inches 31.4 cm
Weight 11 lbs. 4.95 kg
Dimensions with Drawer English Metric
Height 9.25 inches 23.5 cm
Width 6.75 inches 17.15 cm
Depth 12.375 inches 31.4 cm
Weight 14 lbs. 6.3 kg
* Specification based on following environmental conditions: 20°C; 50% RH; 2 sigma
