DKG-119 User Manual V-27 (20.04.2012)
- 6 -
The positive terminal of the DC Supply shall
be connected to this terminal. The unit
operates on both 12V and 24V battery
systems.
Connect the magnetic pickup signal to these
inputs.
Power supply negative connection.
Current transformer
inputs, 5A-AC
Connect the generator current transformer
terminals to these inputs. Do not connect the
same current transformer to other instruments
otherwise a unit fault will occur. Connect each
terminal of the transformer to the unit‟s related
terminal. Do not use common terminals. Do
not use grounding. Correct polarity of
connection is vital. If the measured power is
negative, then change the polarity of the
current transformer. The secondary winding
rating shall be 5 Amperes. (For ex. 200/5
Amps).
Analogue fuel level sender connection. Do not
connect the sender to other devices. The input
has programmable resistor value and
connects to various senders.
Analogue high temperature sender
connection. Do not connect the sender to
other devices. The input has programmable
characteristics and connects to any kind of
sender.
Analogue oil pressure sender connection. Do
not connect the sender to other devices. The
input has programmable characteristics and
connects to any kind of sender.
Connect the charge alternator‟s D+ terminal to
this terminal. This terminal will supply the
excitation current and measure the voltage of
the charge alternator.
This relay is used for fuel solenoid control.
This relay controls the engine cranking.
This relay has programmable function,
selectable from a list.
This relay has programmable function,
selectable from a list.
