DATAKOM DKG-705 User’s Manual
705_USER.doc - 11 -
Group
Screen
Description Contents
1 5 Engine parameters Engine rpm, Battery Voltage
Coolant Temperature, Fuel Level
Oil Temperature, Oil Pressure
1 6 Genset power Genset Active Power (KW) , Genset Frequency
Genset Apparent Power (KVA), Genset Power Factor
(cosΦ
ΦΦ
Φ)
Genset Reactive Power (KWr)
1 6 Alarm list If no alarm exists this screen will display ‘END OF ALARM
LIST’. Existing alarms, load_dumps and warnings will be
displayed as one screen for each entry. Switching to the
next entry will be made with the MENU button.
Group
Screen
Description Contents
2 1
Genset phase U parameters Phase to Neutral Voltage, Phase Active Power (KW)
Phase Current , Phase Apparent Power (KVA)
Phase Power Factor, Phase Reactive Power (KWr)
2 2
Genset phase V parameters Phase to Neutral Voltage, Phase Active Power (KW)
Phase Current , Phase Apparent Power (KVA)
Phase Power Factor, Phase Reactive Power (KWr)
2 3
Genset phase W parameters Phase to Neutral Voltage, Phase Active Power (KW)
Phase Current , Phase Apparent Power (KVA)
Phase Power Factor, Phase Reactive Power (KWr)
2 4
Synchronoscope Governor Output (%)I AVR Output(%)
Voltage RU, Phase Angle (degrees)
Phase U Voltage, Genset Frequency
Phase R Voltage, Mains Frequency
2 5
Soft transfer parameters Remaining Duration
Governor Output (%), AVR Output(%)
Genset Active Power (KW), Gen. Reactive Power (KWr)
Target Active Power (KW), Target React. Power (KWr)
2 6
Date, time, engine hours Date, Time
Engine Hours Run
2 7
Service display Time to Service
Engine Hours to Service
2 8
Total power counters Total Genset Active Power (KW-h)
Total Genset Apparent Power (KVA-h)
Total Genset Reactive Power (KWr-h)
2 9
Statistical counters Total Engine Cranks
Total Genset Runs
Total Genset on Load
2 10
Mains phase R parameters Phase to Neutral Voltage, Phase Active Power (KW)
Phase Current , Phase Apparent Power (KVA)
Phase Power Factor, Phase Reactive Power (KWr)
2 11
Mains phase S parameters Phase to Neutral Voltage, Phase Active Power (KW)
Phase Current , Phase Apparent Power (KVA)
Phase Power Factor, Phase Reactive Power (KWr)
2 12
Mains phase T parameters Phase to Neutral Voltage, Phase Active Power (KW)
Phase Current , Phase Apparent Power (KVA)
Phase Power Factor, Phase Reactive Power (KWr)
Group Screen
Description Contents
3 1…32
Event logging This group comprises 32 screens, each screen
displaying one recorded event, starting from the most
recent one.
