4.3 Warnings
Definition Source Description
Low Oil Press.Switch Digital Input
High Eng.Temp.Switch Digital Input
Emergency Stop Digital Input
Low Coolant Level Digital Input
Alternator High Temp. Digital Input
High Oil Temp. Digital Input
Overload Digital Input
Low Fuel Level Digital Input
Battery Charger Fail Digital Input
Spare Alarm 7 Digital Input
Spare Alarm 6 Digital Input
Spare Alarm 5 Digital Input
Spare Alarm 4 Digital Input
Spare Alarm 3 Digital Input
Spare Alarm 2 Digital Input
Spare Alarm 1 Digital Input
These warnings are set depending on the digital input settings. The
related program parameters are P_700 to P_776.
Synchronization Fail Internal Set if the phase and voltage synchronization is not successful
before the expiration of Synchronization Fail Timeout (P_A07).
Gen Under-Frequency Phase-U
Set if the genset frequency goes under the Low Frequency
Warning (P_517) limit for Frequency Timer (P_520) period.
Gen Over-Frequency Phase-U
Set if the genset frequency goes over the High Frequency
Warning (P_519) limit for Frequency Timer (P_520) period.
High Battery Voltage Internal
Set if the battery voltage goes over the High Battery Voltage
Warning (P_611) limit.
Low Fuel Level Analog
Input
Set if the fuel level measured from analog input goes under the Low
Fuel Level Warning (P_609) limit.
High Oil Temperature Analog
Input
Set if the oil temperature measured from analog input goes over the
High Oil Temperature Warning (P_607) limit.
High Coolant
Temperature
Analog
Input
Set if the coolant temperature measured from analog input goes
over the High Coolant Temperature Warning (P_605) limit.
Low Oil Pressure
Measured
Analog
Input
Set if the oil pressure measured from analog input goes under the
Low Oil Pressure Warning (P_603) limit.
Mains Phase Sequence
Fail
R-S-T
Set if the mains phase sequence is not correct and Ignore Phase
Order (P_A06) parameter is ‘0’.
Charge Failure Charge
input
Set if the Charge input (terminal_31) is pulled to battery negative
when the engine is running.
Low Battery Voltage Internal
Set if the battery voltage goes under the Low Battery Voltage
Warning (P_612) limit.
AVR Control Fail Internal
Set if the AVR control output has gone to the low or high limit
value for 1 second.
GOV Control Fail Internal
Set if the GOV control output has gone to the low or high limit
value for 1 second.
Low Engine Speed Magnetic
Pickup
Set if the engine rpm goes under the Low rpm Warning (P_614)
limit. If the Crank Teeth Count (P_619) is set to ‘0’, this warning will
be disabled.
High Engine Speed Magnetic
Pickup
Set if the engine rpm goes over the High rpm Warning (P_616)
limit. If the Crank Teeth Count (P_619) is set to ‘0’, this warning will
be disabled.
