DATAKOM DKG-705 User’s Manual
705_USER.doc - 54 -
Program Group: 11
This group of programs defines the calibration coefficients for the voltage and current
measurements.
This group is strictly reserved for manufacturing process and must not
be modified. Otherwise faulty measurements and unpredicted operation
may occur.
Group
Param.
Definition Min
Max Description
11 B00
Phase R Calibration
11 B01
Phase S Calibration
11 B02
Phase T Calibration
11 B03
Phase U Calibration
11 B04
Phase V Calibration
11 B05
Phase W Calibration
11 B06
Current R Calibration
11 B07
Current S Calibration
11 B08
Current T Calibration
11 B09
Current U Calibration
11 B10
Current V Calibration
11 B11
Current W Calibration
11 B12
Battery Voltage
Calibration
0 60000
Each parameter defines the sensitivity of one
measurement input. If the parameter increases, the
input becomes more sensitive and reads a higher
value.
The calibration must be verified with a certified
calibrated test equipment.
