DATALOGIC
2
After Dragon™ M Setup, read one of the following codes to set desired aiming
system timeout.
 aiming system disabled
Ì$+BX0$-AÎ
300 ms
Ì$+BX1$-FÎ
500 ms
Ì$+BX2$-KÎ
1 sec
Ì$+BX3$-PÎ
READING ANGLE
Successful scanning is obtained by tilting the reader with respect to the barcode
to avoid direct reflections that impair the reading performance, see the figure
below.
OK Not Advised
