Datalogic DS2100 - MECHANICAL INSTALLATION

DS2100
6
2
2.2 MECHANICAL INSTALLATION
DS2100 can be installed to operate in different positions. The four screw holes (M4 x
5) on the body of the reader are for mechanical fixture (Figure A, 1). The diagrams
below give the overall dimensions of the scanner and mounting bracket and may be
used for installation.
Refer to par. 2.4 for correct positioning.
DS2100
23.3
0.92
14.5
0.57
84
3.3
A
5
0.098
10.3
0.4
40
1.57
B
0.4
10.3
40
1.57
14.6
0.57
M 4 n° 4
1.3
34
mm
inch
68
2.68
46
1.81
MOUNTING BRACKET
9
4.2
7.8
20°
2.5
73
42
R 40
4.2
90°
30
13.8
17.5
2.5
23
mm
4.2 n° 2
1 x 45° n° 2
Figure 3 - Overall dimensions
