READING FEATURES
31
3
DS2100-1XX4
Testarossa™
2
1
0
1
5
4
3
2
3
4
5
(in)
01 32106
(in)
45 789
0 20 40 60 80 100 120 140 160 180 200 220 240 260
(mm)
120
100
80
60
40
20
0
20
40
60
80
100
120
(mm)
280
11
300
12
0.20 mm
(8 mils)
≥
0.50 mm
(20 mils)
0.30 mm
(12 mils)
NOTE: (0,0) is the center of the laser beam output window.
CONDITIONS
Code = Interleaved 2/5 or Code 39
PCS = 0.90
"Pitch" angle = 0°
"Skew" angle = 10°
"Tilt" angle = 0°
Code Resolution* = High – for 0.20 mm (8 mils) codes and 0.30 mm, (12
mils) codes
Standard – for 0.50 mm (20 mils) codes and greater
* Parameter selectable in WinHost.
