DS6300 COMMON FEATURES
31
Reading Diagrams:
DS6300-105-0XX (Oscillating Mirror) – Resolution: 0.50 mm/20 mils
CONDITIONS
Code = Interleaved 2/5 o
r
Code 39
PCS = 0.90
Pitch angle = 0°
Skew angle = 10° - 20°
Tilt angle = 0°
Focus
Position = 60
8
4
0
12
(in)
50
40
30
20
0
(cm)
10
-10
-20
-30
-40
-50
16
20
-16
-20
-12
-8
-4
-60
-24
60
24
Focus
Position = 100
0 8 20
(in)
12 16 24 28
0 20 30 40 50 60 70 80 90
(cm)
100
3632 40 44
48
52 56
110 120 130 140
Focus
Position = 0
150
User Interface:
RS232 PC-side connections
1
5
9 6
9-pin male connector
13
25 14
1
25-pin male connector
Pin Name Pin Name
2 RX 3 RX
3 TX 2 TX
5 GND 7 GND
7 RTS 4 RTS
8 CTS 5 CTS
