TECHNICAL FEATURES
10
10 TECHNICAL FEATURES
ELECTRICAL FEATURES
Input Power
Supply Voltage 10 - 30 Vdc
Maximum Consumption 0.6 - 0.2 A; 6 W
Serial Interfaces
Main Serial Interface SW programmable: RS232; RS485 FD and HD
Baudrate 1200 - 115200
Auxiliary RS232
Baudrate 1200 - 115200
ID-NET™ RS485 Half-Duplex
Baudrate Up to 1 MBaud
Inputs
Input 1 (External Trigger), Input 2 Optocoupled, polarity insensitive
Voltage 10 to 30 Vdc
Current Consumption 12 mA max.
Minimum Pulse Duration 5 ms.
Outputs
Output 1, Output 2 Optocoupled
V
CE
30 Vdc max.
Collector Current 40 mA continuous max.; 130 mA pulsed max.
V
CE saturation
1V at 10 mA max.
Power Dissipation
80 mW max. at 45 °C (ambient temperature)
OPTICAL FEATURES
Light Source Semiconductor laser diode
Wave Length In the range 630 to 680 nm
Safety Class Class 2 - EN 60825-1; Class II - CDRH
READING FEATURES (Note 1)
Scan Rate (software programmable) 600 to 900 scans/sec
Aperture Angle 50°
Maximum Reading Distance
Maximum Resolution
See reading diagrams
ENVIRONMENTAL FEATURES
Operating Temperature (Note 2)
0° to +50 °C (+32° to +122 °F)
Storage Temperature
-20° to +70 °C (-4° to +158 °F)
Humidity max. 90% non condensing
Vibration Resistance 14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz;
EN 60068-2-6 2 g @ 70 to 200 Hz; 2 hours on each axis
Shock Resistance 30g; 11 ms;
EN 60068-2-27 3 shocks on each axis
Protection Class IP65
Ambient Light Rejection 30,000 LUX
PHYSICAL FEATURES
Mechanical Dimensions 85 x 101 x 42 mm (3.3 x 4 x 1.7 in)
Weight 570 g (20.1 oz.)
Note 1: Further details given in par. 7.3.
Note 2: If the reader is used in high temperature environments (over 40 °C), use of the Beam Shutter is advised (see the
Genius™ configuration program) and/or a thermally conductive support (such as the metal bracket provided).
91
