Datalogic DX8200A

DX8200A QUICK GUIDE
13
Minimum Code Height for Omnidirectional Reading (mm)
Conveyor Speed (m/s) 0.5 1 1.5 2 2.5 3
0.25
9 11 13 15 17 19
0.30
10 11 14 16 18 20
0.33
11 12 14 16 18 20
0.38
12 13 15 17 19 21
0.50
15 16 17 19 21 23
0.72
20 22 23 24 25 27
Code 39
Code Resolution (mm)
1.00
27 28 29 30 32 33
Ratio 3:1; Interdigit = Module Size
Table 2
Minimum Code Height for Omnidirectional Reading (mm)
Conveyor Speed (m/s) 0.5 1 1.5 2 2.5 3
0.25
8 10 12 14 16 18
0.30
9 11 13 15 17 19
0.33
9 11 13 15 18 20
0.38
10 12 14 16 18 20
0.50
12 14 16 18 20 22
0.72
16 18 19 21 24 26
Code 128 – Ean 128
Code Resolution (mm)
1.00
22 23 24 26 28 30
Table 3
Minimum Code Height for Omnidirectional Reading (mm)
Conveyor Speed (m/s) 0.5 1 1.5 2 2.5 3
0.25
8 10 12 14 16 18
0.30
9 11 13 15 17 19
0.33
9 11 13 15 18 20
0.38
10 12 14 16 18 20
0.50
13 14 16 18 20 22
0.72
17 18 19 21 24 26
Codabar
Code Resolution (mm)
1.00
23 24 25 26 28 30
Ratio 3:1; Interdigit = Module Size
Table 4
Minimum Code Height for Omnidirectional Reading (mm)
Conveyor Speed (m/s) 0.5 1 1.5 2 2.5 3
0.25
8 9 11 13 15 18
0.30
9 10 12 14 16 18
0.33
9 10 12 14 16 19
0.38
10 11 13 15 17 19
0.50
12 13 14 16 19 21
0.72
16 18 19 20 21 23
EAN 8-13, UPC-A
Code Resolution (mm)
1.00
22 23 24 25 26 27
Table 5
