Datalogic DX8200A User Manual

DX8200A QUICK GUIDE
4
Model Description:
DX8200A - 3 X Y Z
Power:
0 = VDC
O
p
tical Resolution:
1 = Medium resolution
Communication Type:
0 = Standard version
1 = Ethernet version
2 = High resolution
3 = Very High resolution
1 = VAC
2 = Profibus version
3 = DeviceNet version
Accessories:
NAME Description Part Number
PWR-120 J-box power unit 110/230 VAC 24 V 120 W 93ACC1530
PWR-240 J-box power unit 110/230 VAC 24 V 240 W 93ACC1070
PWR-480 J-box power unit 110/230 VAC 24 V 480 W 93ACC1080
BTK-8100 Bus terminator kit (5 pcs) 93ACC1090
BTK-8102 Double terminator kit (2 pcs) 93A051287
PLL-8000 Optocoupled PLL device 93ACC1280
US-BOX C-BOX mounting bracket to station frame (10 pcs) 93ACC1777
FS-1 Frame shaper (8 pcs) 93ACC1750
CAB-DX8000 DX8200A Power Cable VAC 93A051333
CAB-DX8001 DX8200A Power Cable VAC (US) 93A051334
CAB-8100 10 wire shielded cable D 9.5 mm – 50 m 93ACC1120
CAB-8101 17-pin scanner/scanner connection cable 1.2 m 93A051020
CAB-8102 17-pin scanner/scanner connection cable 2.5 m 93A051030
CAB-8105 17-pin scanner/scanner connection cable 5 m 93A051040
CAB-8305 Power and bus return cable (last Slave) 5 m 93A051268
CAB-8310 Power and bus return cable (last Slave) 10 m 93A051336
CAB-8402 No power cable 2.5 m 93ACC1758
CAB-8405 No power cable 5 m 93ACC1759
CAB-6011 26-pin scanner to C-BOX 100 1 m 93A051221
CAB-6012 26-pin scanner to C-BOX 100 2 m 93A051222
CAB-6015 26-pin scanner to C-BOX 100 5 m 93A051223
CAB-6502 Fam 6K-8K cross cable 2.5 m 93A051288
CAB-6505 Fam 6K-8K cross cable 5 m 93A051289
CAB-8605 Power and Lonworks termination cable (Master) 5 m 93A051290
CAB-DX8000 Power cable DX8200A VAC (EU) 93A051333
CAB-DX8001 Power cable DX8200A VAC (US) 93A051334
Sentinel-5 Supervisor (up to 5 arrays) 93A101004
Sentinel-10 Supervisor (up to 10 arrays) 93A101005
Sentinel-32 Supervisor (up to 32 arrays) 93A101007
C-BOX 100 Passive Connection Box 93ACC1510
MEP-542 Photocell kit – PNP 93ACC1727
MEP-543 Photocell kit – NPN 93ACC1728
OEK-2 Optical encoder kit (10 m cable + spring) 93ACC1770
OEK-1 Optical encoder kit + 10 m cable 93ACC1600
US-BOX C-BOX Mounting Bracket to station frame (10 pcs) 93ACC1777
UPT-80 DX8200A – DX8200 Adapter 93ACC1757

Datalogic DX8200A Specifications

General

Scan speed	1000 sec/page
Sensor type	Laser
Dimensions (WxDxH)	470 x 300 x 147 mm
Standard interfaces	RS-232, RS-485
Power requirements	30 VCD
Power consumption (standby)	30 W
Keys quantity	3 keys
Product color	Black
LED indicators	Charging, Power
Housing material	Steel
International Protection (IP) code	IP64
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	11000 g
