Technical Features
Quick Reference Guide 21
Technical Features
Item Description
Physical Characteristics
Color
White/Grey
Black/Grey
Dimensions
Height 7.1” / 181mm
Length 3.9” / 100mm
Width 2.8” / 71mm
Weight (without cable) Approximately 6.0 ounces/169 g
Electrical Characteristics
Voltage & Current
GD4130 model:
Input current at 5V = 360 mA (max)
2.5 mA (RS-232 sleep mode)
2.5 mA (USB suspend)
Input Power = 1.9W max in the 5V±5% range
GD4110 model:
Input current at 5V = 340 mA (max)
2.5 mA (RS-232 sleep mode)
2.5 mA (USB suspend)
Input Power = 1.8W max in the 4.5÷14V range
Performance Characteristics
Light Source
Dual LEDs
Tilt (Roll) Tolerance ± 35° from normal
Pitch (Yaw) Tolerance ± 65°
Skew Tolerance ± 65°
Field of View 10.0” (25.4cm) wide at 12.5” (31.8cm) from the reader
Depth of Field (Typical)
3 mil – 2.9” to 4.7” (7.5cm to 12cm)
13 mil
*
– 1.2” to 23.6” (3cm to 60cm)
20 mil – 1.2” to 31.5” (3cm to 80cm)
Minimum Element Width 3 mil
Print Contrast Minimum 15% minimum reflectance
Decode Capability
UPC/EAN/JAN, P2 /P5 add-ons; Code 39; Code 32; Code 128;
Code 128 ISBT; Code 128 add-ons; Interleaved 2 of 5; Standard
2 of 5; Code 11; Codabar; EAN 128; GS1 DataBar™ Omnidirec-
tional, GS1 DataBar™ Limited, GS1 DataBar™ Expanded, Code 4,
Code 5, Follett 2 of 5.
