LED and Beeper Indications
Quick Reference Guide 23
LED and Beeper Indications
The imager’s beeper sounds and its LED illuminates to indicate
various functions or errors on the reader. A “Green Spot” also
lights to indicate a good read. The tables below list these indi-
cations. One exception to the behaviors listed in the tables is
that the reader’s functions are programmable, and may or may
not be turned on. For example, certain indications, such as the
power-up beep can be disabled using programming barcode la-
bels. Reference the PRG for a more detailed list.
Indication LED Beeper
Power-up
LED flashes/blinks on
power-up, however, this may
be too rapid to view. With a
USB interface, the LED blinks
until enumeration with the
host is completed.
Imager beeps four times at
highest frequency and vol-
ume upon power-up.
Good Read
LED behavior for this indica-
tion is configurable using the
PRG.
One beep at current fre-
quency, volume,
mono/bi-tonal setting upon
a successful label scan.
ROM Failure 200ms on / 200ms off
Imager sounds one error
beep at highest volume for
200 mS.
Limited Scanning
Label Read
N/A
Imager 'chirps' six times at
the highest frequency and
current volume.
Imager Disabled
The LED blinks continuously
100mS on / 900 mS off
N/A
