Page #16 background imageLoading...
Page #16 background image
LED and Beeper Indications
14 Gryphon™ i
LED and Beeper Indications
The imager’s beeper sounds and its LED illuminates to indicate
various functions or errors on the reader. A “Green Spot” also
lights to indicate a good read. The tables below list these indi-
cations. One exception to the behaviors listed in the tables is
that the reader’s functions are programmable, and may or may
not be turned on. For example, certain indications, such as the
power-up beep can be disabled using programming barcode la-
bels. Reference the PRG for a more detailed list.
Indication LED Beeper
Power-up
LED flashes/blinks on
power-up, however, this
may be too rapid to view.
With a USB interface, the
LED blinks until enumera-
tion with the host is com-
pleted.
Imager beeps four
times at highest fre-
quency and volume
upon power-up.
Good Read
LED behavior for this
indication is configurable
using the PRG.
One beep at current
frequency, volume,
mono/bi-tonal setting
upon a successful label
scan.
ROM Failure 200ms on / 200ms off
Imager sounds one
error beep at highest
volume for 200 mS.
Limited Scan-
ning Label Read
N/A
Imager 'chirps' six
times at the highest fre-
quency and current vol-
ume.
Imager Disabled
The LED blinks continu-
ously 100mS on / 900 mS
off
N/A
