Technical Specifications
QUICK REFERENCE GUIDE
15
TECHNICAL SPECIFICATIONS
The following table contains Physical and Performance Characteristics, User
Environment and Regulatory information.
PHYSICAL CHARACTERISTICS
Color
Black
Dimensions
Height: 3 cm (1.18'')
Length: 13.5 cm (5.31'')
Width: 5 cm (1.96'')
Weight: 80g (2.82 oz)
ELECTRICAL CHARACTERISTICS
Supply Voltage 5VDC +/-5%
Power Consumption max. 300 mA
Indicators See Table 1 on page 1
ENVIRONMENTAL CHARACTERISTICS
Working Temperature -20° to +50 °C / -4 to +122 °F
Storage
Temperature
-40° to +60 °C / -40 to +140 °F
Humidity 90% non condensing
Protection Class IP40
Regulatory See Regulatory Addendum
BT CHARACTERISTICS
Frequency
working center
2400 to 2483.5 MHz
Typical Range (in open air) 100 m
Max number of devices per base station 7
CLOUD PARAMETERS
MQTT Length Max Scancode Length 1450
Websocket Length Max Scancode Length 2048
Scancode Dataformat Base64
