Datalogic Heron HD313 Series Quick Reference Guide

Setting Up the Reader
2 Heron™ HD3130
Setting Up the Reader
Follow the steps below to connect and get your reader up and com-
municating with its host.
1. Connect the Cable to the reader and the Host as shown below.
2. Configure the Interface (see page 6).
3. Program the Reader starting on page 14 (optional, as needed).
Connecting to the Host Interface
Disconnecting the Cable
USB
WEDGE
RS-232
