Datalogic MAGELLAN 8400 - Interface Related Features; Interface Type

5-12 Magellan
®
8300/8400
Interface Related Features
Interface Type
Specifies the current scanner interface.
INTERFACE (I/F) TYPE
I/F I.D. NUMBER
a
a.
To access a scanner’s interface identification number, place the scanner in Scanner Diagnostic Mode
and view the 7-segment FRU display.
RS-232 Standard 05
RS-232 Wincor-Nixdorf 12
RS-232 Single Cable 20
IBM USB 45
IBM Port 17 04
NOT USER-SELECTABLE
Null Interface
7-segment FRU display indicates 0 at start-up (accompanied by trill beep for
approx. 2 seconds)
