Operating Mode
18 PowerScan™ PBT9501
Operating Mode
Scan Mode
The imager can be set to operate in one of several scan-
ning modes. See the PRG for more information and set-
tings for any of the options:
Trigger Single (Default) —
When the trigger is pulled, scan-
ning is activated until one of the following occurs:
•a programmable duration
1
has elapsed
a label has been read
•the trigger is released
Trigger Hold Multiple
When the trigger is pulled, scan-
ning starts and the product scans until the trigger is
released or “maximum scan on time”
1
has elapsed. Read-
ing a label does not disable scanning. Double Read Time-
out
1
prevents undesired multiple reads in this mode.
Trigger Pulse Multiple
When the trigger is pulled and
released, scanning is activated until programmable dura-
tion
1
has elapsed or the trigger has been pulled again to
transition to another state. Double Read Timeout
1
pre-
vents undesired multiple reads while in this mode.
Flashing —
The reader flashes
1
on and off regardless of the
trigger status.
Always On —
No trigger pull is required to read a bar code.
Scanning is continually on. If the trigger is pulled, the
reader acts as if it is in Trigger Single (Default) Mode. Dou-
ble Read Timeout
1
prevents undesired multiple reads
while in this mode.
Stand Mode —
No trigger pull is required to read a bar
code. Scanning is turned on automatically when an item is
placed in reader’s field of view. If the trigger is pulled, the
reader acts as if it is in Single Read mode. Double Read
Timeout
1
prevents undesired multiple reads while in this
mode.
1. See the Product Reference Guide (PRG) for more information

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Datalogic PowerScan PBT9501 and is the answer not in the manual?

Datalogic PowerScan PBT9501 Specifications

General IconGeneral
Harmonized System (HS) code84716070
TypeHandheld bar code reader
Wavelength680 nm
Sensor typeLED
Scanner type1D/2D
Scanner resolution0.1016 mm
Tilt reading angle0 - 360 °
Pitch reading angle-40 - 40 °
Light levels (direct sunlight)0 - 100000 lx
Linear (1D) barcodes supported-
Optical sensor resolution (W x H)864 x 544 pixels
2D (matrix & stacked) barcodes supportedAztec Code, Data Matrix, Han Xin, MaxiCode, Micro QR Code, QR Code
Bluetooth version3.0
Operating frequency433 - 910 MHz
Standard interfacesBluetooth, RS-232
Connectivity technologyWired & Wireless
CertificationIEC 62471
Product colorBlack, Yellow
LED indicatorsYes
Image formats supportedBMP, JPEG, TIFF
International Protection (IP) codeIP65
Warranty period3 year(s)
Sustainability certificatesREACH, RoHS
Battery life10 h
Battery typeBuilt-in battery
Charging time4.5 h
Input voltage10-30 V
Battery capacity3350 mAh
Power consumption150 mA
Power source typeBattery
AC adapter output voltage110 V
Number of reads per charge60000
Cables includedDC, RS-232
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)0 - 95 %
Weight and Dimensions IconWeight and Dimensions
Depth74 mm
Width110 mm
Height212 mm
Weight380 g
