Datalogic PowerScan PBT9501 User Manual

Error Codes
Quick Reference Guide 27
Error Codes
Upon startup, if the reader sounds a long tone, this means
the reader has not passed its automatic Selftest and has
entered FRU (Field Replaceable Unit) isolation mode. If the
reader is reset, the sequence will be repeated. Press and
release the trigger to hear the FRU indication code.
The following table describes the LED flashes/beep codes
associated with an error found.
INDICATION DESCRIPTION LED BEEPER
Label Pro-
gramming
Mode Accep-
tance of Par-
tial Label
In cases where
multiple labels
must be scanned
to program one
feature, this indica-
tion acknowledges
each portion as it is
successfully
scanned.
N/A
Reader sounds
one short beep at
highest fre-
quency and cur-
rent volume.
Label Pro-
gramming
Mode Accep-
tance of Pro-
gramming
Configuration
option(s) have been
successfully pro-
grammed via labels
and the reader has
exited Program-
ming Mode.
N/A
Reader sounds
one high fre-
quency beep and
4 low frequency
beeps followed by
reset beeps.
Label Pro-
gramming
Mode Cancel
Item Entry
Cancel label has
been scanned.
N/A
Reader sounds
two times at low
frequency and
current volume.
Number of LED
Flashes/Beeps
Error
Corrective
Action
1 Configuration
Contact
Helpdesk for
assistance
2 Interface PCB
6Digital PCB
11 Imager

Datalogic PowerScan PBT9501 Specifications

General

Harmonized System (HS) code	84716070
Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	LED
Scanner type	1D/2D
Scanner resolution	0.1016 mm
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
Optical sensor resolution (W x H)	864 x 544 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Han Xin, MaxiCode, Micro QR Code, QR Code
Bluetooth version	3.0
Operating frequency	433 - 910 MHz
Standard interfaces	Bluetooth, RS-232
Connectivity technology	Wired & Wireless
Certification	IEC 62471
Product color	Black, Yellow
LED indicators	Yes
Image formats supported	BMP, JPEG, TIFF
International Protection (IP) code	IP65
Warranty period	3 year(s)
Sustainability certificates	REACH, RoHS
Battery life	10 h
Battery type	Built-in battery
Charging time	4.5 h
Input voltage	10-30 V
Battery capacity	3350 mAh
Power consumption	150 mA
Power source type	Battery
AC adapter output voltage	110 V
Number of reads per charge	60000
Cables included	DC, RS-232
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
