Datalogic PowerScan PBT9501 User Manual

LED and Beeper Indications
26 PowerScan™ PBT9501
Table 3. Error Indicators
Programming Mode - The following indications ONLY
occur when the reader is in Programming Mode
.
INDICATION DESCRIPTION LED BEEPER
Link Attempt
The reader is try-
ing to link to the
base
Slow
Flashes
N/A
Configuration
Alignment
Reader and Base
are aligning the
parameters' con-
figuration
Fast Flashes N/A
Link
The reader has
successfully
linked to the base
N/A
3 beeps of
ascending fre-
quency
Unlink
The reader has
unlinked from
the base
N/A
3 beeps of
descending fre-
quency
ROM Failure
There is an error
in the reader's
software/pro-
gramming
Flashes
Reader sounds
one error beep at
highest volume.
Limited
Scanning
Label Read
Indicates that a
host connection
is not estab-
lished.
N/A
Reader 'chirps' six
times at the high-
est frequency and
current volume.
Reader
Disabled
The reader has
been disabled by
the host.
The LED
blinks con-
tinuously
N/A
INDICATION DESCRIPTION LED BEEPER
Label Pro-
gramming
Mode Entry
A valid program-
ming label has
been scanned.
LED blinks
continu-
ously
Reader sounds
four low fre-
quency beeps.
Label Pro-
gramming
Mode Rejec-
tion of Label
A label has been
rejected.
N/A
Reader sounds
three times at
lowest frequency
and current vol-
ume.

Datalogic PowerScan PBT9501 Specifications

General

Harmonized System (HS) code	84716070
Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	LED
Scanner type	1D/2D
Scanner resolution	0.1016 mm
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
Optical sensor resolution (W x H)	864 x 544 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Han Xin, MaxiCode, Micro QR Code, QR Code
Bluetooth version	3.0
Operating frequency	433 - 910 MHz
Standard interfaces	Bluetooth, RS-232
Connectivity technology	Wired & Wireless
Certification	IEC 62471
Product color	Black, Yellow
LED indicators	Yes
Image formats supported	BMP, JPEG, TIFF
International Protection (IP) code	IP65
Warranty period	3 year(s)
Sustainability certificates	REACH, RoHS
Battery life	10 h
Battery type	Built-in battery
Charging time	4.5 h
Input voltage	10-30 V
Battery capacity	3350 mAh
Power consumption	150 mA
Power source type	Battery
AC adapter output voltage	110 V
Number of reads per charge	60000
Cables included	DC, RS-232
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
