Datalogic PowerScan PBT9501 User Manual

Quick Reference Guide i
Table of Contents
END USER SOFTWARE LICENSE AGREEMENT (EULA) ............... iii
Software Product Policy ............................................................... vii
Description .......................................................................................1
General Features ....................................................................1
Using the PowerScan™ PBT9501 ...................................................2
Installing the Battery Pack ............................................................3
Charging the Batteries ..........................................................6
Changing the Batteries ................................................ 6
Programming ...................................................................................7
Using Programming Bar Codes ............................................7
Configure Other Settings .......................................................7
Resetting Product Defaults .................................................. 7
Set Date and Time ..........................................................................8
Linking the Reader .......................................................................... 9
Link Datalogic RF Devices to Base.............................. 9
Linking to a Bluetooth Adapter in Serial Port Profile
(Slave) Mode .................................................................. 9
Linking to a Bluetooth Adapter in HID mode........... 10
Variable PIN Code ....................................................... 11
HID Country Mode .........................................................................12
HID Caps Lock State ......................................................................16
HID Alt Mode ..................................................................................17
Power Off .......................................................................................17
Operating Mode .............................................................................18
Scan Mode ............................................................................18
Motion Aiming Control ........................................................19
Pick Mode .......................................................................................20
Multiple Label Reading ........................................................20
Technical Specifications ...............................................................21
LED and Beeper Indications .........................................................25
Error Codes ....................................................................................27
Cleaning ..........................................................................................28
Datalogic Limited Factory Warranty ...........................................29
Ergonomic Recommendations ....................................................31
Support Through the Website .....................................................32
Hex-Numeric Keypad ....................................................................33
For HID Variable Pin Code only.................................. 35

Datalogic PowerScan PBT9501 Specifications

General

Harmonized System (HS) code	84716070
Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	LED
Scanner type	1D/2D
Scanner resolution	0.1016 mm
Tilt reading angle	0 - 360 °
Pitch reading angle	-40 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
Optical sensor resolution (W x H)	864 x 544 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Han Xin, MaxiCode, Micro QR Code, QR Code
Bluetooth version	3.0
Operating frequency	433 - 910 MHz
Standard interfaces	Bluetooth, RS-232
Connectivity technology	Wired & Wireless
Certification	IEC 62471
Product color	Black, Yellow
LED indicators	Yes
Image formats supported	BMP, JPEG, TIFF
International Protection (IP) code	IP65
Warranty period	3 year(s)
Sustainability certificates	REACH, RoHS
Battery life	10 h
Battery type	Built-in battery
Charging time	4.5 h
Input voltage	10-30 V
Battery capacity	3350 mAh
Power consumption	150 mA
Power source type	Battery
AC adapter output voltage	110 V
Number of reads per charge	60000
Cables included	DC, RS-232
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
