Datalogic PowerScan PBT9501

Technical Specifications
22 PowerScan™ PBT9501
PERFORMANCE CHARACTERISTICS
Light Source LED
Roll (Tilt) Tolerance ± 180°
Pitch Tolerance ± 40°
Skew (Yaw) Toler-
ance
± 40°
Print Contrast
Minimum
15% minimum
reflectance
Item Description
Resolution
PBT9501 PBT9501-HP
Max resolution 1D
4 mils
Max resolution 2D
7.5 mils
1D 2.5 mil
2D 4 mil
DEPTH OF FIELD (TYPICAL)
a
a. 13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade
A,300 lux ambient light, 20°C, label inclination 10°
Symbology Standard Model: High Performance:
Code 39
4 mils: 6-17 cm
20 mils: 4-55 cm
40 mils: 4-85 cm
2.5 mils: 2-6 cm
20 mils: 3-70 cm
40 mils: 3-110 cm
EAN 13 13 mils: 4-48 cm 13 mils: 3-60 cm
PDF-417 10 mils: 2-25 cm 10 mils: 2-30 cm
DataMatrix
7.5 mils: 7-14 cm
10 mils: 4-18 cm
4 mil: 2-6 cm
10 mil: 2-20 cm
