Datalogic PowerScan PD8530 Quick Reference Guide

Technical Features
20 PowerScan™ PD8530 Family
PowerScan™ PD8530™ WA
Reading distances are measured from the nose of the reader.
NOTE: Typical performance at 20ºC / 68ºF on high quality barcodes.
Optical Features
Focus distance 115 mm
Field of view 54° (H) x 45° (V)
Horizontal field of view at
distance (d) in mm
1.04d + 40
Vertical field of view at dis-
tance (d) in mm
0.40d + 10
Max Resolution
Linear codes -
mm (mils)
PDF 417 – mm
(mils)
Datamatrix –
mm (mils)
0.13 (5 mils) 0.13 (5 mils) 0.19 (7.5 mils)
Depth of field*
1D (linear):
X-dimension
mm (mils)
DOF
cm (in)
Code39 0.13 (5)
2.5 to 10.0
(0.98 to 3.94)
0.51 (20)
1.5 to 32
(0.59 to 12.60)
EAN 13 0.33 (13)
1.5 to 26.0
(0.59 to 10.24)
2D:
X-dimension
mm (mils)
DOF
cm (in)
PDF417 0.13 (5)
3.0 to 10.5
(1.18 to 4.13)
0.25 (10)
1.5 to 21.5
(0.59 to 8.46)
QR 0.19 (7.5)
5.5 to 8.5
(2.17 to 3.35)
0.25 (10)
3.0 to 12.5
(1.18 to 4.92)
DataMatrix 0.19 (7.5)
5.5 to 8.5
(2.17 to 3.35)
0.25 (10)
3.0 to 12.5
(1.18 to 4.92)
Skew ±40°
Pitch ±35°
Rotation 360°
Print Contrast (Min.) 15%
