Datalogic PowerScan PD9531-AR Quick Reference Guide

Using the PowerScan™ PD9531-AR
Quick Reference Guide 3
Using the PowerScan™ PD9531-AR
The PowerScan™ PD9531-AR normally functions by cap-
turing and decoding 1D and 2DS codes. The intelligent
aiming system indicates the field of view which should be
positioned over the code. The reader is equipped with an
aiming system which helps to aim the target.
Figure 1- Aiming System
If enabled, a partial trigger press produces a red spot,
which should be aimed over the code center to get the
best reading performance. By completely pressing the
trigger the illumination area appears and the code scan-
ning starts.
Aiming Pointer
Scan the following symbols to enable or disable the aim-
ing pointer.
Aiming Pointer = disable
Aiming Pointer = enable
The field of view indicated by the aiming system and the
illumination area will be smaller when the reader is closer
to the code and larger when it is farther from the code.
Symbologies with smaller bars or elements (mil size)
should be read closer to the unit. Symbologies with larger
bars or elements (mil size) should be read farther from the
unit.

Datalogic PowerScan PD9531-AR Specifications

General

Brand	Datalogic
Model	PowerScan PD9531-AR
Category	Barcode Reader
Language	English
