Datalogic PowerScan PM9501-AR Series User Manual

LED and Beeper Indications
Quick Reference Guide 17
Programming Mode - The following indications ONLY
occur when the reader is in Programming Mode
.
INDICATION DESCRIPTION LED BEEPER
Label Pro-
gramming
Mode Entry
A valid program-
ming label has
been scanned.
LED blinks
continu-
ously
Reader sounds
four low fre-
quency beeps.
Label Pro-
gramming
Mode Rejec-
tion of Label
A label has been
rejected.
N/A
Reader sounds
three times at
lowest fre-
quency and
current volume.
Label Pro-
gramming
Mode Accep-
tance of Par-
tial Label
In cases where
multiple labels
must be scanned
to program one
feature, this indi-
cation acknowl-
edges each portion
as it is success-
fully scanned.
N/A
Reader sounds
one short beep
at highest fre-
quency and
current volume.
Label Pro-
gramming
Mode Accep-
tance of Pro-
gramming
Configuration
option(s) have
been successfully
programmed via
labels and the
reader has exited
Programming
Mode.
N/A
Reader sounds
one high fre-
quency beep
and 4 low fre-
quency beeps
followed by
reset beeps.
Label Pro-
gramming
Mode Cancel
Item Entry
Cancel label has
been scanned.
N/A
Reader sounds
two times at
low frequency
and current
volume.
