Datalogic PowerScan PM9501 Series User Manual

LED and Beeper Indications
Quick Reference Guide 19
Programming Mode - The following indications ONLY
occur when the reader is in Programming Mode
.
INDICATION DESCRIPTION LED BEEPER
Label Pro-
gramming
Mode Entry
A valid program-
ming label has
been scanned.
LED blinks
continu-
ously
Reader sounds
four low fre-
quency beeps.
Label Pro-
gramming
Mode Rejec-
tion of Label
A label has been
rejected.
N/A
Reader sounds
three times at
lowest fre-
quency and cur-
rent volume.
Label Pro-
gramming
Mode Accep-
tance of Par-
tial Label
In cases where
multiple labels
must be scanned
to program one
feature, this indica-
tion acknowledges
each portion as it is
successfully
scanned.
N/A
Reader sounds
one short beep
at highest fre-
quency and cur-
rent volume.
Label Pro-
gramming
Mode Accep-
tance of Pro-
gramming
Configuration
option(s) have been
successfully pro-
grammed via labels
and the reader has
exited Program-
ming Mode.
N/A
Reader sounds
one high fre-
quency beep
and 4 low fre-
quency beeps
followed by
reset beeps.
Label Pro-
gramming
Mode Cancel
Item Entry
Cancel label has
been scanned.
N/A
Reader sounds
two times at
low frequency
and current vol-
ume.

Datalogic PowerScan PM9501 Series Specifications

General

Scanner Type	Handheld
Connectivity	Wireless
Drop Resistance	Withstands repeated drops from 2.0 m / 6.6 ft onto concrete
Sealing	IP65
Operating Temperature	-20 to 50 °C / -4 to 122 °F
Type	Industrial
Storage Temperature	-40 to 70 °C / -40 to 158 °F
IP Rating	IP65
Radio Range	100 m / 328 ft
Radio Frequency	433 MHz; 910 MHz
Decode Capability	1D / 2D
Scanning Technology	Laser or Imager
Interface	RS-232, USB
Supported Barcodes	All standard 1D and 2D barcodes
Resolution	4 mil (1D Codes); 5 mil (2D Codes)
Humidity	5 to 95% (non-condensing)
Drop Specification	2.0 m / 6.6 ft onto concrete
Dimensions	8.3 x 4.3 x 2.9 in
Power Supply	Rechargeable Li-ion battery or USB power
