Datalogic QuickScan i QD2100 Product Reference Guide

Label ID
Product Reference Guide 99
Label ID — continued
Table 18. Label ID Examples
STEP ACTION EXAMPLES
1. Scan the ENTER/EXIT barcode (Scanner enters Programming Mode)
2.
Determine placement of the Label
ID characters BEFORE or AFTER
with regard to scanned data using
Label ID Control on
page 100
Enable as Prefix Enable as Suffix Enable as Prefix Enable as Suffix
3.
Scan the barcode selecting the
symbology type you wish to
designate label ID characters for
using
Label ID Symbology
Selection, starting on page
101
.
GS1 DataBar
Omnidirectional
Code 39
Interleaved 2 of 5 Code 32
4.
Custom Label ID example (desired
characters):
D B * = C 3 +P H
5.
Find hex equivalents from the
ASCII table (inside back cover),
then scan in these digits/
characters using the barcodes in
the section:
Keypad, starting
on page 291
. f you make a
mistake before the last character,
scan the CANCEL barcode to
abort and not save the entry
string. You can then start again at
the beginning.
44 42 2A 3D 43 33 2B 50 48
6. Scan theENTER/EXIT barcode (Scanner exits Label ID entry)
7.
Scan the ENTER/EXIT barcode
once again
(Scanner exits Programming Mode)
Result:
DB*[barcode data] [barcode data]=C3 +[barcode data] [barcode data]PH

Datalogic QuickScan i QD2100 Specifications

General

Scan speed	8 sec/page
Wavelength	610 nm
Tilt angle range	-65 - 65 °
Decoding standards	1D / GS1 DataBar China Post GS1 DataBar Expanded/ Stacked/ Stacked Omnidirectional
Dimensions (WxDxH)	170 x 66 x 71 mm
Standard interfaces	RS-232, USB, Keyboard wedge
Input voltage	5 V
Power consumption	340 mA
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	121.9 g
