Technical Features
24 QuickScan™ Mobile
DATA FORMAT: code identifier enabled, code length not transmitted, no
header, terminator = CR, character replacement disabled, address stamping
disabled, address delimiter disabled.
WEDGE DEFAULT SETTINGS (only for Quickscan M2 Type:130)
USA keyboard, caps lock off, caps lock auto-recognition enabled; num lock
unchanged, inter-character and inter-code delay disabled.
DATA FORMAT: code identifier disabled, code length not transmitted, no
header, terminator = ENTER, character replacement disabled, address
stamping disabled, address delimiter disabled.
IBM DEFAULT SETTINGS (only for Quickscan M2 Type:110)
DATA FORMAT: IBM Standard, code identifier disabled, no header, no
terminator
PEN DEFAULT SETTINGS
Interpret operating mode, minimum output pulse 600 μs, conversion to Code
39, overflow medium, output level normal, idle level normal, inter-block delay
disabled.
Technical Features
QuickScan
®
Mobile Reader and Cradle
Electrical Features - READER
Battery Type 1 Lithium battery 700 mAh
Time of recharge Lithium max 6 hours with USB cable
Operating autonomy typical 20000 reads
Indicators LED, Beeper
Max scan rate 235 scans/sec
Electrical Features - CRADLE
Supply voltage
5 VDC ± 5%
Power consumption max. 4 W (charging)
LED Indicators Battery charging red
Charge completed green
Power / Data yellow
Optical Features
Sensor CCD solid state (2088 pixels)
Illuminator LED array
Wavelength 630 ~ 670 nm
Max. LED Output Power 0.33 mW
LED safety class Class 1 EN 60825-1
Reading field see reading table
Max. resolution 0.10 mm, 4 mils
PCS minimum 20% (Datalogic Test Chart)
