2 QuickScan™ Mobile
Reading Angle
QuickScan
TM
Mobile readers automatically scan barcodes at a distance.
Simply aim and pull the trigger. Code scanning is performed along the center
of the light bar emitted from the reading window. This bar must cover the
entire code.
Successful scanning is obtained by tilting the reader with respect to the
barcode to avoid direct reflections, which could impair the reading
performance. See the figures below.
Successful reading is indicated by an audible tone.
OK Not Recommended
Hands-Free Use
When using the QuickScan Mobile on the cradle, remember to lock the reader
by pushing up the locking system as indicated in the following figure.
