36 QS2500
Append: This function allows several symbols to be concatenated and be
treated as a single entry. The QS2500 will not transmit the embedded
appending code (for Code-39, a space). If the append function is enabled
and other symbols are read again with the appended code, then the codes
are transmitted without the code ID, preamble, or prefix. When a symbol
was decoded without the appended code, the data is transmitted without
the code ID and prefix, but the postamble suffix codes are appended. This
function is used when the first character of Code 39 data is a space.
Start/End Transmission: The start and end characters of Code 39 are aster-
isks (*). You can transmit all data digits, including the two asterisks.
Option Bar Code Option
Alphanumeric
Entry
Read
Disable 00
Enable
01*
Checksum Verification
Disable 00*
Enable
01
Checksum Transmission
Disable 00*
Enable
01
Maximum Code Length
Use Global Max. 00*
1–64
01–64
Minimum Code Length
Use Global Min. 00*
1–64
01–64
Truncate Leading
0–15
00–15
00*
Truncate Ending
0–15
00–15
00*
Code ID Setting
00–ff
hex
ASCII
code
00–ff
hex
<*>
$
Start Program

Datalogic QuickScan QS2500 Specifications

General

Wavelength	660 nm
Maximum scan area	102/127 mm
Yaw reading angle	-75 - 75 °
Decoding standards	UPC A, E / EAN 8, 13 / JAN 8, 13, Code 128, Code 93, Pharmacode 39, Code 39, Codabar, Interleaved 2 - 5, Industrial 2 - 5, Matrix 2 - 5, GS1 DataBar, UK/Plessey, MSI/Plessey, Code 16K, Telepen, PDF-417, Code 11
Pitch reading angle	-60 - 60 °
Input voltage	5 V
Power consumption	250 mA
Dimensions (WxDxH)	74 x 114 x 185 mm
Certification	UL, cUL, FCC-A, EN 55022-B, VCCI-A, IEC 60825 Class 1 LED, EU RoHS
Product color	Gray
Storage temperature (T-T)	-30 - 65 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	179 g
