42 QS2500
Codabar
Read: Format:
Checksum Verification: The checksum is presented as the sum mod 16 of
the numerical values of all data digits.
Checksum Transmission: When this option is enabled, the QS2500 will
transmit the checksum.
Maximum/Minimum Code Length: Same as Code 39. See page 35.
Truncate Leading/Ending: Same as UPC-A. See page 27.
Code ID Setting: Same as UPC-A. See page 27.
Insertion Group Selection: Same as UPC-A. See page 27.
Start/End Type: Codabar has four pairs of Start/End patterns. Select one
pair to match your application.
Start/End Transmission: Same as Code 39. See page 36.
Start Data Digits (Variable) Checksum (Optional) End
Option Bar Code Option
Alphanumeric
Entry
Read
Disable 00*
Enable 01
Checksum Verification
Disable 00*
Enable 01
Checksum Transmission
Disable 00*
Enable 01
To Next Page
