Technical Specifications
QUICK REFERENCE GUIDE
29
QUICKSCAN™ QW2500
DOF - DEPTH OF FIELD (TYPICAL)
A
Symbology
DOF range
Code 39
5 mil: 0.5 - 23.0 cm (0.19" - 9.0")
10 mil: 0.5 - 37 cm (0.19" - 14.5")
EAN13 13 mil: 1 - 40.0 cm (0.39" - 15.7")
PDF417 6.7 mil: 0.5 - 13.5 cm (0.19" - 5.3")
Datamatrix 10 mil: 1.0 - 15.5 cm (0.39" - 6.1")
Code 128 5 mil: 2.5 - 18.0 cm (9.8" - 7.0")
QR Code 20 mil: 1.0 - 33 cm (0.39" - 12.9")
Max Resolution
1D Min = 3 mil
PDF417 Min = 5 mil
Datamatrix Min = 6 mil
a. All 1D codes are Code 39. All labels grade A, typical environmental light, 20°C,
label inclination 10°
DECODE CAPABILITY
1D Bar Codes
UPC/EAN/JAN (A, E, 13, 8); UPC/EAN/JAN (including P2 /P5); UPC/EAN/JAN
(including; ISBN / Bookland & ISSN); UPC/EAN Coupons; Code 39 (including full
ASCII); Code 39 Trioptic; Code39 CIP (French Pharmaceutical); LOGMARS (Code 39
w/ standard check digit enabled); Danish PPT; Code 32 (Italian Pharmacode 39);
Code 128; Code 128 ISBT; Interleaved 2 of 5; Standard 2 of 5; Interleaved 2 of 5 CIP
(HR); Industrial 2 of 5; Discrete 2 of 5; Matrix 2 of 5; IATA 2of5 Air cargo code; Code
11; Codabar; Codabar (NW7); ABC Codabar; EAN 128; Code 93 ; MSI; PZN; Plessey;
Anker Plessey; GS1 DataBar Omnidirectional; GS1 DataBar Limited; GS1 DataBar
Expanded; GS1 DataBar Truncated; DATABAR Expanded Coupon.
2D / Stacked Codes
The QuickScan™ 2500 scanner is capable of decoding the following symbologies
using multiple frames (i.e. Multi-Frame Decoding):
Data Matrix; Inverse Data Matrix; Data Matrix is configurable for the following
parameters:; Normal or Inverted; Square or Rectangular Style; Data length (1 -
3600 characters); Maxicode; QR Codes (QR, Micro QR and Multiple QR Codes);
Aztec; Postal Codes - (Australian Post; Japanese Post; KIX Post; Planet Code;
Postnet; Royal Mail Code (RM45CC); Intelligent Mail Barcode (IMB); Sweden Post;
Portugal Post); LaPoste A/R 39; PDF-417; MacroPDF; Micro PDF417; GS1 Com-
posites (1 - 12); French CIP13
a
; GS1 DataBar Stacked; GS1 DataBar Stacked Omni-
directional; GS1 DataBar Expanded Stacked; GSI Databar Composites; Chinese
Sensible Code; Inverted 2D codes
b
.
a. It is acceptable to handle this with ULE
b. The SW can apply the Normal/Reverse Decoding Control to the following sym-
bologies: Data Matrix, QR, Micro QR, Aztec and Chinese Sensible Code.
