3.9 DIAGNOSTIC ERROR MESSAGES
3.9.1 SC6000 error message syntax:
WS#xxx where WS means Working Standby and xxx is the error number as listed in the table:
WA#xxx where WA means Working Active and xxx is the error number as listed in the table:
PS#xxx where PS means Protecting Standby and xxx is the error number as listed in the table:
PA#xxx where PA means Protecting Active and xxx is the error number as listed in the table:
Diagnostic
Error Number
Meaning
[136] Redundancy Role Exchange Warning: this warning is generated on the Stand-
by SC6000 to signal that the exchange of the Redundancy Role is in progress.
[137] Redundancy Serial Communication Failure: the communication through the
redundancy serial interface (PWO to PWO) has failed.
[138] Redundancy Warning: the redundancy is not available. The Master Stand-by
SC6000 does not work OR an encoder or presence sensor error is generated
on the Master Stand-by SC6000.
[139] Lonworks Communication Failure: the communication through the Lonworks
interface has failed.
[141] Master Failure: the communication to the Master (Active or Stand-by) is not
available.
[143] Power Failure: a power drop has occurred in the PWO power supply.
[145] Presence Sensor Failure: a presence sensor warning has occurred only on the
Stand-by SC6000 of the redundant system and is transmitted by the Active
SC6000.
[147] Encoder Failure: an encoder warning has occurred only on the Stand-by
SC6000 of the redundant system and is transmitted by the Active SC6000.
[163] Max Consecutive Lost Parcels: The Standby controller recognizes n more
consecutive Parcels than the Active controller.
[165] Max % Of Lost Parcels (Out Of 100 Parcels): The Standby controller recognizes
n out of 100 Parcels counted that the Active controller has not counted.
3.9.2 SYNCHRONIZED Slave (Scanners) Error message syntax:
ss#xxx where ss is the slave scanner number and xxx is the error number as listed in the table:
Diagnostic
Error Number
Meaning
[16] No Scan: scan signal missing
[81] DIGITIZER: Motor Failure – no motor activity
[83] DIGITIZER: Laser Failure – no laser activity
[97] OSCILLATING MIRROR: Motor Failure – no oscillating mirror motor activity
[113] FLASH: Motor Failure – no flash motor activity
[129] No Sync: no flash sync signal
[130] Encoder Failure Timeout: no encoder signal for more than the programmed
timeout.
