MOUNT AND POSITION THE DEVICE
PRODUCT REFERENCE GUIDE 2
MOUNT AND POSITION THE DEVICE
1. To mount the Smart-VS, use the mounting bracket to obtain the most suitable
position for the device. The most common mounting configuration is shown in the
figure below.
Figure 4 - Positioning with Mounting Bracket
Skew
Tilt
