Allegro2 F-1
Appendix F
Specifications
Printing
Type: Direct thermal or thermal transfer
Resolution: 203 dots per inch (8 dots/mm)
Print Speed: 2.0 −3.0" (51 mm −76 mm) per second
Barcode Modules: 5 mil to 110 mil (.0005" - .110") “X”
dimension in picket or ladder orientation
Maximum Print Width: 4.1" (104mm)
Maximum Print Length: 8.25" (210mm) with standard RAM; up to
20.25" (514mm) with optional 512K memory
module
White Space Slew Rate: 2.0"−3.0" (51mm−76 mm) per second
Maximum Fields Per 200; 5K data per label maximum
Label:
Minimum Dot Size: 0.005" (0.125mm) square
Optional Dot Sizes: 0.010" (0.250mm) vertical; 0.015" (0.381mm)
vertical; 0.010" (0.250mm) horizontal
Label Backfeed: For use with optional Cutter or Peel and Present.
