E-4203/E-4204/E-4304 13
5. Slide the Media Guide and Media Hub Flange to the edge of the
media.
6. Close the Printhead Carrier Assembly and press down until it locks
into place.
7. Close the cover and press the Feed button several times to position
the media and ensure proper tracking.
(If the printer does not correctly sense the top of each label, as
denoted by the FAULT Light, it may be necessary to perform the
Calibration Procedure, Section 4.6.)
; Note: The printer is factory set to use 4-inch media (and ribbon, if thermal
transfer equipped). When using a different width of media/ribbon,
please refer to Chapter 5.
